HikVision 12 Volts 8 Channel Cctv Power Supply Unit

Hikvision — 12V 8-Channel CCTV Power Supply — Specifications

Power Output

• Total output: 60W, 12 VDC/1A per channel (8 channels)
• Cable length compensation: Normal (12 VDC) / Long (13.5 VDC) / Ex-Long (15 VDC)
• Ripple & noise: 0.15 Vp-p (150 mV)

Input

• Input voltage: 150–285 VAC, 47–63 Hz (wide voltage input)
• AC input connector: C8

Protection

• Over current / short circuit / over voltage protection
• Good EMC (electromagnetic compatibility) performance

Output

• DC output connector: DC plug / grid terminal
• LED indicator: Green

Build

• Appearance: White
• Dimensions: 144mm x 109.5mm x 33mm (5.67" x 4.31" x 1.30")
• Compact size, suited for CCTV installations

Operating Conditions

• Operating temperature: 0°C to 40°C (32°F to 104°F), humidity 10%–95% (non-condensing)
• Storage temperature: -40°C to 80°C (-40°F to 176°F), humidity 5%–95% (non-condensing)

In the Box

• 8-way PSU, power cable (EUR plug)
