Hikvision — 16-Channel 1U H.265+ DVR — HDTVI/AHD/Analog/IP — Specifications

Video Input

• 16-channel analog video input via BNC, supports HDTVI/AHD/CVI/CVBS signal types
• Up to 18-ch IP camera inputs, each up to 5 MP resolution
• Long-distance transmission: max. 1200m for 720p Turbo HD signal over UTP and coaxial cable

Recording

• Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• One-key H.264+ compression improves encoding efficiency by up to 50%, reducing storage costs
• Encoding capability up to 1080p Lite @ 15 fps
• Supports 1080p Lite on all channels — image effect similar to full 1080p when enabled

Smart Features

• Deep learning-based human/vehicle target classification, Motion Detection 2.0

Audio

• Audio input via coaxial cable
• Supports HDTVI two-way audio technology on all channels

Storage & Playback

• 1 SATA interface, up to 10TB capacity per HDD
• Smart search for efficient playback

Video Output

• HDMI/VGA simultaneous output

Network

• Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF

Build

• Weight: ≤1.1 kg (without HDD)
• Form factor: 1U rackmount
