HikVision | 32 Channel Digital Video Recorder H.265 Pro+ Dvr

Hikvision — 32-Channel 720p 1U H.265 Turbo HD DVR — Specifications

Video Input

• 32-channel analog video input via BNC interface (1.0 Vp-p, 75Ω)
• Supports HDTVI/AHD/CVI/CVBS/IP signal input, auto-adaptive
• 2-ch (up to 18-ch) IP camera input, each up to 5MP, supporting H.265+/H.265/H.264+/H.264 IP cameras
• Max distance: 1200m for 720p HDTVI signal

Video Output

• 1-ch HDMI: up to 1920×1080/60Hz
• 1-ch VGA: up to 1920×1080/60Hz
• 1-ch CVBS (BNC), PAL: 704×576, NTSC: 704×480

Recording

• Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding resolution: 1080p lite/720p/720p lite/WD1/4CIF/VGA/CIF
• Video bitrate: 32 Kbps to 4 Mbps
• Audio compression: G.711u, 64 Kbps
• Stream type: Video, or Video & Audio

Smart Features

• Deep learning-based Motion Detection 2.0 with human/vehicle classification
• Reduces false alarms from objects like leaves and lights
• Quick search by object or event type

Storage

• 2 SATA interfaces, supporting up to 10TB capacity
• Smart search for efficient playback

Audio

• 1-ch RCA audio input (2.0 Vp-p, 1KΩ)
• 32-ch coaxial audio input via BNC
• 32-ch two-way audio support via BNC, including from DVR local, web, and Hik-Connect

Network

• Hik-Connect and DDNS support for easy remote network management

Form Factor

• 1U rackmount chassis
