Hikvision DS-7632NI-K2/16P — 32-Channel PoE Network Video Recorder — Specifications

Camera Support

• Up to 32-ch IP camera inputs
• Compatible with Hikvision and third-party network cameras

Video

• Video formats: H.265+/H.265/H.264+/H.264
• Decoding capacity: Up to 2-ch @ 8MP or 4-ch @ 4MP or 8-ch @ 1080p
• Incoming bandwidth: Up to 256 Mbps
• Outgoing bandwidth: 160 Mbps
• H.265+ compression reduces storage space by up to 75%
• Stream over TLS encryption for secure stream transmission

Video Output

• HDMI: 4K (3840×2160)/30Hz, 2K (2560×1440)/60Hz, 1920×1080/60Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz
• VGA: 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz
• Both HDMI and VGA support independent video output

Connectivity

• 16 independent PoE network interfaces (plug & play)
• 1 self-adaptive 10/100/1000 Mbps Ethernet interface
• Serial interfaces: RS-232, RS-485
• Alarm I/O: 16/4 (expandable to 16/8)
• USB: 2x

Storage

• 2 SATA interfaces for HDD connection, up to 16TB capacity per HDD
• 8/16-ch synchronous playback
• Power consumption: ≤20W (without HDD, DVD-R/W, or PoE)

Smart Functions

• VCA (Video Content Analytics) support
• ANPR (Automatic Number Plate Recognition) support
• Smart playback

Network & Management

• Network detection (delay, packet loss monitoring)
• Compatible with Hik-Connect

Build

• Form factor: 1U rackmount
