HikVision Ds-7204hghi-m1 | 4 Channel 1uh.265+ Digital Video Recorder Hdtvi/ahd/analog/ip Dvr

Hikvision DS-7204HGHI-M1 — 4-Channel 1U H.265+ DVR — HDTVI/AHD/Analog/IP — Specifications

Video Input

• 4-channel analog video input via BNC (1.0 Vp-p, 75Ω), supports coaxitron connection
• HDTVI/AHD/CVI/CVBS video input
• Up to 5-ch IP camera input (up to 2MP each)
• Max distance: 1200m for 720p HDTVI signal

Video Output

• 1-ch HDMI: up to 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz
• 1-ch VGA: same resolution options as HDMI

Recording

• Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding resolution: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF (1080p stream); 720p/WD1/4CIF/VGA/CIF (720p stream)
• Frame rate: Up to 30fps depending on stream
• Sub-stream: 4CIF@15fps; CIF/QVGA@25/30fps

Smart Features

• Deep learning-based Motion Detection 2.0 with human/vehicle classification, reducing false alarms

Audio

• Audio via coaxial cable
• Supports HDTVI two-way audio technology on all channels

Storage & Playback

• 1 SATA interface, up to 4TB–6TB capacity per HDD (varies by source)
• Smart search for efficient playback

Network

• Hik-Connect & DDNS support for easy remote network management
• Protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS

Form Factor

• 1U rackmount

In the Box (typical)

• DVR unit, mouse, AC/DC 12V power adapter, CD with manual/software
